Sizes 15.5, 17.5, 18.5, 19.5, 21.5, 23"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
G2 Geometry, 130mm travel
Front suspension RockShox Sektor Silver RL, Solo
Air, TurnKey lockout, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 140mm travel
Rear suspension RockShox Deluxe RL, 210x52.5mm
Shifters Shimano Deore, 10-speed
Front derailleur Shimano Deore, high direct mount
Rear derailleur Shimano Deore, Shadow
Cassett e Shimano HG50, 11-36, 10-speed
Crank Race Face Ride, 36/22
Wheels Bontrager alloy hubs, Boost110 front,
Boost148 rear; SUNringlé Duroc 40 SL 28-hole rims
Tyres Bontrager Chupacabra, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x2.80"
Saddle Bontrager Evoke 1.5
Seatpost Bontrager SSR, 2-bolt head, 31.6mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise,
750mm width
Stem Bontrager Rhythm Comp, Knock Block, 31.8mm,
0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano M315 hydraulic disc
Key Features
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP and
Full Floater
••Straight Shot stiffness, Knock Block
frame defence
