Sizes 15.5, 17.5, 18.5, 19.5, 21.5, 23"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
G2 Geometry, 130mm travel
Front suspension Fox Rhythm 34 Float, Grip
adjustable damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 140mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 210x52.5mm
Shifters SRAM GX, 11-speed
Rear derailleur SRAM GX, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM GX 1000, 32T X-Sync
Wheels Bontrager sealed bearing hubs, alloy axle
Boost110 front, Boost148 rear; SUNringlé Duroc 40 SL
28-hole rims
Tyres Bontrager Chupacabra, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x2.80"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager Line, 35mm, 15mm rise,
750mm width
Stem Bontrager Line, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
Fox Rhythm Series fork
Fox Performance Series RE:aktiv shock
Bontrager sealed bearing hubs
SRAM GX 1x11 drivetrain
