Sizes 13.5, 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5,
23" (29" wheels)
Frame Alpha Gold Aluminium w/semi-integrated head
tube, mechanically formed and butted tubing, race
geometry, internal front derailleur routing, rack and
mudguard mounts, G2 Geometry on 29ers
Front suspension RockShox Recon Silver, coil spring,
preload, rebound, TurnKey lockout, G2 Geometry
w/51mm offset on 29ers, 100mm travel (13.5 :
80mm travel)
Shifters SRAM X5, 10-speed
Front derailleur SRAM X7
Rear derailleur SRAM GX
Cassett e SRAM PG-1020, 11-36, 10-speed
Crank SRAM S1000, 36/22
Pedals Wellgo nylon platform
Wheels Formula DC20 LW alloy front hub; Formula
DC22 LW alloy rear hub; Bontrager Mustang Elite
Tubeless Ready 28-hole rims
Tyres Bontrager XR2, 29x2.20" front, 29x2.00" rear
(13.5 & 15.5: 27.5x2.20")
Saddle Bontrager Evoke 1.5
Seatpost Bontrager SSR, 2-bolt head, 27.2mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset 1-1/8" threadless, semi-integrated,
semi-cartridge bearings
Brakeset Shimano M315 hydraulic disc
Key Features & Upgrades (?)
••Race-ready spec: 2x drivetrain options,
lockout, hydraulic discs
••Light, precise race frame for a fast,
refined ride
••Ride the fastest wheel that fits with Smart
Wheel Size
••Extended size range gives you a better fit for
a better ride
RockShox Recon Silver fork
Formula lightweight alloy hubs
Bontrager Mustang Elite Tubeless rims
SRAM 2x10 drivetrain
