Sizes 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5, 23"
(29" wheels)
Frame Alpha Platinum Aluminium, E2 tapered head
tube, internal derailleur routing, PF89.5, balanced post
mount brake, Closed Convert dropouts, G2 Geometry
on 29ers
Front suspension RockShox Recon Silver RL, Solo
Air spring, remote lockout, E2 tapered steerer,
G2 Geometry w/51mm offset on 29ers, 100mm travel
Shifters Shimano Deore, 10-speed
Front derailleur Shimano Deore
Rear derailleur Shimano Deore XT, Shadow
Cassett e Shimano HG50, 11-36, 10-speed
Crank Race Face Ride, 36/22
Wheels Bontrager sealed bearing hubs; Bontrager
Mustang Elite Tubeless Ready 28-hole rims
Tyres Bontrager XR1 Expert, Tubeless Ready,
Inner Strength sidewalls, aramid bead, 29x2.20"
(15.5: 27.5x2.20")
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager alloy, 2-bolt head, 27.2mm,
8mm offset
Handlebar Bontrager alloy, 31.8mm, 5mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset Shimano M425 hydraulic disc
Key Features
••Every feature of this XC race 29/27.5 is
designed to go fast
••Ride the fastest wheel that fits with Smart
Wheel Size
••Super-light hydro-formed aluminium frame is
built for speed
••Racy geometry gets you lower, shortens
the chainstays
