Sizes 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5, 23"
(29" wheels)
Frame OCLV Mountain Carbon, IsoSpeed, E2 tapered
head tube, internal derailleur routing, balanced post
mount brake, PF92, Boost148 and G2 Geometry
on 29ers
Front suspension RockShox Reba RL, Solo Air, Motion
Control damper, remote lockout, E2 tapered steerer,
Boost110, G2 Geometry w/51mm offset on 29ers,
100mm travel
Shifters Shimano Deore, 10-speed
Front derailleur Shimano Deore, low direct mount
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano HG50, 11-36, 10-speed
Crank Race Face Ride, 36/22
Wheels Bontrager sealed bearing, alloy axle, Center
Lock hubs, Boost110 front, Boost148 rear; Bontrager
Mustang Elite Tubeless Ready 28-hole rims
Tyres Bontrager XR1 Expert, Tubeless Ready,
Inner Strength sidewalls, aramid bead, 29x2.20"
(15.5: 27.5x2.20")
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager alloy, 2-bolt head, 31.6mm,
8mm offset
Handlebar Bontrager alloy, 31.8mm, 5mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset Shimano M425 hydraulic disc
Key Features
••Smooth IsoSpeed decoupler: ride faster,
stronger, longer
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••OCLV Mountain Carbon frame is fast, light,
and trail tough
••Ride the fastest wheel that fits with Smart
Wheel Size
