Sizes 15.5, 17.5, 18.5, 19.5, 21.5”
Frame Alpha Platinum Aluminium, ABP, Boost148,
EVO link, E2 tapered head tube, Knock Block steerer
stop, internal derailleur and dropper post routing,
150mm travel
Front suspension RockShox Yari RL, Solo Air, Motion
Control damper, lockout, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 150mm travel
Rear suspension RockShox Deluxe RT3 RE:aktiv, tuned
by Trek Suspension Lab, 230x57.5mm
Shifters Shimano Deore XT M8000, 11-speed
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano M7000 SLX, 11-42, 11-speed
Crank Miranda Delta, 15T
Pedals Wellgo nylon platform
Wheels Bontrager sealed bearing, alloy axle hubs,
Boost110 front, Boost148 rear; SUNringlé Duroc 40 SL
28-hole rims
Tyres Bontrager Chupacabra, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x2.80”
Saddle Bontrager Evoke 2, chromoly rails
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager alloy, 31.8mm, 5mm rise,
750 width
Stem Bontrager Rhythm Comp, Knock Block, 31.8mm,
0 degree
Headset FSA Knock Block IS-2, E2, sealed
alloy cartridge
Brakeset Shimano M615 hydraulic disc, 203mm
front/180mm rear rotors
Controller Bosch Intuvia Performance
Batt ery Bosch Powerpack Performance 500 downtube
Motor Bosch Performance CX
Key Features
••Trek MTB legacy makes Powerfly a true
mountain bike
••Knock Block frame defence protects from
spinning handlebars
••The more capable 150mm frame is up
for anything
••A powerful central-mount Bosch motor, for
speeds up to 25 km/h
