Sizes 15.5, 17.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
seatstay, alloy chainstay, ABP, Full Floater, EVO
link, E2 tapered head tube, Control Freak internal
routing, Carbon Armor, PF121, 197x12 hub spacing,
120mm travel
Front suspension RockShox Bluto RL, Solo Air, TurnKey
lockout, E2 tapered steerer, 150x15mm Maxle Lite,
120mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 7.25x1.875"
Shifters SRAM X1, 11-speed
Rear derailleur SRAM X01, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank Race Face Next, 30T Direct
Mount Narrow-Wide
Wheels Trek Wampa Carbon 80 SL, Tubeless Ready,
150x15 front, 197x12 rear
Tyres Bontrager Hodag, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x3.80"
Saddle Bontrager Evoke 3, titanium rails
Seatpost Bontrager Drop Line 125, under-bar
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
15mm rise, 750mm width
Stem Bontrager Line, 35mm, 0 degree
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Guide hydraulic disc
Key Features & Upgrades (?)
••OCLV Mountain Carbon frame is ultra light,
ultra tough
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Faster 27.5 x 4 wheels bounce less and
roll farther
••Go tubeless with Bontrager TLR for
trail-hugging confidence
OCLV Mountain Carbon frame
Trek Wampa carbon wheels
SRAM X1/X01 drivetrain
Race Face Next crank
